Commercial 1.97" Capacity Motorized Radius Cutter for Print & Copy Centers

Description: Stop trimming sharp edges by hand. The Akiles Diamond-5 is a commercial-grade electric corner rounder designed to bring high-speed automation and retail-quality precision directly to your desktop. Driven by a high-torque internal motor and operated via a hands-free foot pedal, this industrial workhorse effortlessly glides through a 1.97-inch stack of paper (approx. 500 sheets of 20lb bond) in a single one-second cycle—completely removing manual strain and accelerating your finishing workflow.

Constructed with a rugged all-metal chassis, the Diamond-5 features specialized mechanical alignment guides that square your document lifts perfectly before the blade descends. Whether you are radiusing heavy cardstock covers, thick 10-mil laminated badges, poly covers, or fully bound booklets, this machine delivers a smooth, razor-sharp edge every time, ensuring your presentations stand out with a premium executive finish.

Why the Diamond-5 is a Critical Workflow Asset:

• High-Capacity 1.97" Cutting Depth: Processes nearly two full inches of material or a complete bound booklet in a single cycle, slashing production times compared to hand-lever equipment.

• Uniform Motor-Driven Pressure: The electric drive mechanism provides a consistent, vertical cutting stroke, ensuring the top sheet and the bottom sheet match perfectly without page sliding or jagged edges.

• Interchangeable Die Versatility: Designed for quick-change capability. Easily swaps between standard radiuses from 1/8" to 3/8", straight cuts, or thumb-cut styles to match any project specification (dies sold separately).

• Hands-Free Foot Pedal Control: Keeps both of the operator's hands free to align, seat, and firmly stabilize heavy cardstock or slippery laminated sheets against the corner guides.

• Built-In Safety Guard: A clear plastic protective shield surrounds the reciprocating blade assembly, maximizing operator safety without obscuring the view of the alignment path.

• Integrated Waste Tray & Storage Drawer: Collects paper trimmings instantly to keep your workstation clean, while a built-in tool tray holds your alternative dies and alignment wrenches.

Technical Specifications:

• Operation: Electric (Heavy-Duty Foot Pedal).

• Maximum Capacity: 1.97" (50mm) thickness per cycle.

• Cycle Speed: Approx. 30 cuts per minute.

• Standard Included Blade: 1/4" Radius Die (Interchangeable).

• Construction: Heavy-gauge industrial metal chassis (55 lbs).
