Heavy-Duty 4:1 Pitch Oval Hole Punch & Motorized Spiral Finishing Station

Description: Stop wasting time hand-twisting coils into your documents. The Akiles CoilMac-ECI Plus is a commercial-grade hybrid workstation designed to accelerate your binding workflow. While the punching is handled by an extra-long, heavy-duty manual lever that punches up to 25 sheets effortlessly, the assembly process is fully automated. Once your holes are punched, simply hold your coil against the built-in, full-size Electric Coil Inserter and watch it thread through the document in seconds.

As part of the elite "Plus" line, this machine punches 4mm x 5mm Oval Holes instead of standard circles. This subtle engineering upgrade creates a wider path for the plastic filament, reducing insertion friction by up to 40%. This makes it incredibly fast and easy to bind thick, multi-page manuals and proposals that would normally jam on a standard round-hole machine.

Why the CoilMac-ECI Plus is the Smarter Workflow Upgrade:

• Integrated Electric Roller Inserter: Features a full-size, motorized roller operated by a convenient foot pedal. It spins plastic coils through the punched holes instantly, removing the most tedious manual step from your production line.

• The Oval Hole Advantage: Punches precision 4mm x 5mm oval holes. The oval shape gives the coil more "wiggle room," allowing for dramatically faster threading—especially on large, 300+ page books.

• 54 Fully Disengageable Pins: Every single pin can be independently pulled to customize the punch pattern for any document length, guaranteeing a flawless, centered layout without partial "half-holes" on the edges.

• Heavy-Duty "Power Lever" Handle: The ergonomic, U-shaped handle provides maximum mechanical leverage, allowing you to punch up to 25 sheets of 20lb paper at a time with minimal physical effort.

• Adjustable Depth of Punch: Fine-tune the hole distance from the edge of the paper. Use a deeper margin for thick 2" books to prevent pages from tearing out, or a shallow margin for thin documents to ensure easy page turning.

Technical Specifications:

• Operation: Manual Punch & Electric Roller Inserter.

• Punching Capacity: Up to 25 sheets (20lb bond).

• Hole Pattern: 4:1 Pitch Oval Holes (4mm x 5mm).

• Throat Design: 13" Width with an Open Throat for oversized documents.

• Die Pins: 54 independently disengageable pulling pins.

• Construction: Heavy-gauge industrial all-metal chassis.
