Commercial 16-Sheet Heavy-Duty Desktop Folder and Saddle Stapling Machine

Description: Transform loose printed sheets into perfectly folded, center-stapled booklets instantly. The Akiles BookletMac is a commercial-grade electric booklet maker engineered for quick-print centers, corporate print hubs, school districts, and religious institutions. Driven by a high-torque electric motor system, this automated workstation handles up to 16 sheets of 20lb paper (making a complete 64-page booklet) in a single one-second cycle—completely eliminating manual folding strain and accelerating your document output.

Equipped with dual heavy-duty stapling heads and precise mechanical alignment guides, the BookletMac delivers retail-sharp consistency across all standard document formats. Simply drop your flat, printed sheet sets into the top feed slot; the machine automatically activates its sensors, squares the paper block, fires two uniform staples perfectly along the spine centerline, and outputs a crisply folded booklet into the collection tray.

Why the BookletMac is a Vital Asset for Your Print Fleet:

• One-Second Fold and Staple Pass: Combines folding and saddle-stitching into a single high-speed operation, replacing tedious manual folding benches.

• Massive 16-Sheet Capacity: Effortlessly processes thick document profiles up to 16 sheets of standard bond or heavy-gauge cardstock covers, producing sharp 64-page finished booklets.

• Dual Precision Stapling Heads: Features adjustable stapling positions with 5 distinct slots along the spine path, ensuring structural holding power for both small pamphlets and oversized reports.

• Versatile Operational Modes: Switch seamlessly between Automatic Mode (triggered instantly via built-in throat sensors upon paper insertion) or Manual Mode via a simple push-button interface.

• Multi-Format Paper Alignment: Rapid-adjust side guides handle sheet configurations from compact 4.75" x 8.25" booklets up to massive 11.75" x 17" menus and newsletters.

• Heavy-Duty All-Metal Chassis: Built with solid steel internal gears and structural frames to prevent flexing and misalignment over years of continuous high-volume production.

Technical Specifications:

• Operation Type: Semi-Automatic Electric (Continuous Motor/Sensor Trigger).

• Maximum Capacity: Up to 16 sheets of 20lb bond paper per cycle.

• Processing Speed: Up to 800 completed booklets per hour.

• Stapling Heads: Dual heavy-duty heads (Uses standard 24/6 or 26/6 staples).

• Maximum Sheet Size: 11.75" x 17" (Produces an 8.5" x 11" booklet).

• Chassis Build: Industrial-grade all-metal framework (Approx. 55 lbs).
